Category	Video
Video Types Supported	XVGA
Video Processor	ET4000
Highest Resolution Supported	1024 x 768
Data Bus Type	16-bit ISA
Memory Type	DRAM
Maximum Onboard Memory	512KB

CONNECTIONS
Purpose	Location
15-pin analog video port	CN1

VIDEO INTERFACE MODE SELECTION
Mode		JP1
»	Interfaced	Open
	Non-Interfaced	Closed

VIDEO INTERRUPT SELECTION
IRQ	JP2
2/9	Pins 2 & 3 closed
7	Pins 1 & 2 closed

DRAM CONFIGURATION
Size	Bank 0	Bank 1
256KB	(2) 44256	None
512KB	(2) 44256	(2) 44256
