STANDARD MICROSYSTEMS CORPORATION
ARCNET PC650
|
NIC Type |
ARCnet |
|
Transfer Rate |
2.5Mbps |
|
Data Bus |
16-bit ISA |
|
Topology |
Star |
|
Wiring Type |
Unshielded twisted pair |
|
Boot ROM |
Available |
|
NODE ADDRESS |
||||||||
|
Node |
SW2/1 |
SW2/2 |
SW2/3 |
SW2/4 |
SW2/5 |
SW2/6 |
SW2/7 |
SW2/8 |
|
0 |
- |
- |
- |
- |
- |
- |
- |
- |
|
1 |
Off |
On |
On |
On |
On |
On |
On |
On |
|
2 |
On |
Off |
On |
On |
On |
On |
On |
On |
|
3 |
Off |
Off |
On |
On |
On |
On |
On |
On |
|
4 |
On |
On |
Off |
On |
On |
On |
On |
On |
|
251 |
Off |
Off |
On |
Off |
Off |
Off |
Off |
Off |
|
252 |
On |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
253 |
Off |
On |
Off |
Off |
Off |
Off |
Off |
Off |
|
254 |
On |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
255 |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
Off |
|
Note: Node address 0 is used for messaging between nodes and must not be used. A total of 255 node address settings are available. The switches are a binary representation of the decimal node addresses. Switch 1 is the Least Significant Bit and switch 8 is the Most Significant Bit. The switches have the following decimal values: switch 1=1, 2=2, 3=4, 4=8, 5=16, 6=32, 7=64, 8=128. Turn off the switches and add the values of the off switches to obtain the correct node address. (On=0, Off=1) |
||||||||
|
BOOT ROM |
||
|
Setting |
JP2 |
|
|
» |
Disabled |
Open |
|
|
Enabled |
Closed |
|
INTERRUPT REQUEST |
||||||
|
IRQ |
JP3A |
JP3B |
JP3C |
JP3D |
JP3E |
JP3F |
|
3 |
Closed |
Open |
Open |
Open |
Open |
Open |
|
4 |
Open |
Closed |
Open |
Open |
Open |
Open |
|
5 |
Open |
Open |
Closed |
Open |
Open |
Open |
|
7 |
Open |
Open |
Open |
Closed |
Open |
Open |
|
9 |
Open |
Open |
Open |
Open |
Closed |
Open |
|
10 |
Open |
Open |
Open |
Open |
Open |
Closed |
|
I/O BASE ADDRESS |
||||
|
Address |
SW1/1 |
SW1/2 |
SW1/3 |
|
|
» |
300h |
Off |
On |
On |
|
|
260h |
On |
On |
On |
|
|
290h |
On |
On |
Off |
|
|
2E0h |
On |
Off |
On |
|
|
2F0h |
On |
Off |
Off |
|
|
350h |
Off |
On |
Off |
|
|
380h |
Off |
Off |
On |
|
|
3E0h |
Off |
Off |
Off |
|
DIAGNOSTIC LED(S) |
|||
|
LED |
Color |
Status |
Condition |
|
LED1 |
Red |
On |
Card is being accessed by host computer |
|
LED1 |
Red |
Off |
Card is not being accessed by host computer |
|
LED2 |
Green |
On |
Data is being transmitted or received |
|
LED2 |
Green |
Off |
Data is not being transmitted or received |
|
LED2 |
Green |
blinking |
Network is reconfiguring |
|
BASE MEMORY & BOOT ROM ADDRESS |
||||||
|
Base Address |
Boot ROM Address |
SW1/4 |
SW1/5 |
SW1/6 |
SW1/7 |
SW1/8 |
|
C0000h |
C2000h |
On |
On |
On |
On |
On |
|
C0800h |
C2000h |
On |
On |
On |
On |
Off |
|
C1000h |
C2000h |
On |
On |
On |
Off |
On |
|
C1800h |
C2000h |
On |
On |
On |
Off |
Off |
|
C4000h |
C6000h |
On |
On |
Off |
On |
On |
|
C4800h |
C6000h |
On |
On |
Off |
On |
Off |
|
C5000h |
C6000h |
On |
On |
Off |
Off |
On |
|
C5800h |
C6000h |
On |
On |
Off |
Off |
Off |
|
CC000h |
CE000h |
On |
Off |
On |
On |
On |
|
CC800h |
CE000h |
On |
Off |
On |
On |
Off |
|
CD000h |
CE000h |
On |
Off |
On |
Off |
On |
|
CD800h |
CE000h |
On |
Off |
On |
Off |
Off |
|
D0000h |
D2000h |
On |
Off |
Off |
On |
On |
|
D0800h |
D2000h |
On |
Off |
Off |
On |
Off |
|
D1000h |
D2000h |
On |
Off |
Off |
Off |
On |
|
D1800h |
D2000h |
On |
Off |
Off |
Off |
Off |
|
D4000h |
D6000h |
Off |
On |
On |
On |
On |
|
D4800h |
D6000h |
Off |
On |
On |
On |
Off |
|
D5000h |
D6000h |
Off |
On |
On |
Off |
On |
|
D5800h |
D6000h |
Off |
On |
On |
Off |
Off |
|
D8000h |
DA000h |
Off |
On |
Off |
On |
On |
|
D8800h |
DA000h |
Off |
On |
Off |
On |
Off |
|
D9000h |
DA000h |
Off |
On |
Off |
Off |
On |
|
D9800h |
DA000h |
Off |
On |
Off |
Off |
Off |
|
DC000h |
DE000h |
Off |
Off |
On |
On |
On |
|
DC800h |
DE000h |
Off |
Off |
On |
On |
Off |
|
DD000h |
DE000h |
Off |
Off |
On |
Off |
On |
|
DD800h |
DE000h |
Off |
Off |
On |
Off |
Off |
|
E0000h |
E2000h |
Off |
Off |
Off |
On |
On |
|
E0800h |
E2000h |
Off |
Off |
Off |
On |
Off |
|
E1000h |
E2000h |
Off |
Off |
Off |
Off |
On |
|
E1800h |
E2000h |
Off |
Off |
Off |
Off |
Off |
